Features
& Benefits

  • Blade mast pocket construction features mast panel and 2 mil triax X-Ply mast pocket sides (3 layers) tensioned directly (all 3 layers under tack pulley webbings) – downhaul tension is equalized between the mast panel and the mast pocket resulting in the Racingblade's firm, clean, easy-rotating leading edge
  • Internal vertical and horizontal Kevlar strip applications at cams – defines profile and augments stability
  • Tubed battens with varying carbon content. Top 3 specialized 100% carbon tubes – carbon tubes are lightweight and deliver superior stability at the upper end
  • Unique SDM and RDM mast compatibility. Tekcam2 Large (installed) and Reduced (in sail bag) included with size 8.6 and down
  • Metallic cam interfaces – MCIs eliminate contact point degradation characteristic of cam designs without MCIs
  • X-ply batten pockets that alternate sail sides - using similar material for the batten pocket as the body material minimizes the asymmetric character of applied batten pockets. Pockets made with laminates allow the batten to be centered. These features combine to maintain rotation symmetry. In contrast, same-side dacron pockets promote asymmetrical rotation
  • Streamlined neoprene boom cutout with dual zippers – limits water entry into the mast sleeve, keeping the rig light for fast recoveries
  • Tekcam2 camber inducer design – easy rotation and gentle to your mast
  • Durable IYU250 4-part mast pocket – the perfect material between your mast and the elements
  • 4 mil Dimension Polyant laminated monofilm upper body panels – proven superior performance
  • Trim diamond - leech-release reference: dial into your sailing conditions

Colorways

Design Testimonial by Monty Spindler

Ultra complete slalom race performance.

Magazine test results

Sail Specifications

Description Size Luff Boom Vario Top Extension Cambers Battens Recommended Mast Weight
Racingblade 5.0 Orange 20195.0 m2410 cm174 cmFixed40 cm47Team Edition 3705.16 kg
Racingblade 5.6 Orange 20195.6 m2426 cm180 cmFixed26 cm47Team Edition 4005.3 kg
Racingblade 6.3 Orange 20196.3 m2446 cm196 cmFixed16 cm47Team Edition 4305.63 kg
Racingblade 7.0 Orange 20197.0 m2464 cm206 cmFixed34 cm47Team Edition 4305.93 kg
Racingblade 7.8 Orange 20197.8 m2484 cm224 cmFixed24 cm47Team Edition 4606.18 kg
Racingblade 8.6 Orange 20198.6 m2504 cm228 cmFixed14 cm47Team Edition 4906.42 kg
Racingblade 9.0 Orange 20199.0 m2518 cm230 cmFixed28 cm47Team Edition 4906.84 kg

Ask Monty

"When you have a technical related product question."

Write a question

Knowledge

"Learn and understand our products better."

Learn more

Preferred Webshop

"When you want to buy online direct out of stock."

Buy now

Warranty

"Sorry to hear this happened, let's work out a solution"

Apply

Share your feedback

"Help us to improve to make our products even better than they are."

Give feedback

Nearest dealer

"Visit your nearest local shop who stock Loftsails."

Find out

Frequently
asked questions?

What does 1 Year Unconditional + 1 Year Conditional warranty cover?

Warranty is valid 2 years after date of purchase. When making a warranty claim in the first year the product is unconditionally warranted. When making a warranty claim in the 2nd year the product must have clearly suffered from a manufacturer error.
